Operating Width

30 Inches

30 Inches

Weft bars

3bars

8bars

Max,Tapes Width

Normal 0.2-5.5CM,Special 10CM-60CM

Normal 0.2-5.5CM,Special 10CM-60CM

Gauge Per Inch

12,14,15,18,20

12,14,15,18,20

Density

5-25/cm

5-25/cm

Link chain extension

12 Normal 12- 50(Longer)

12 Normal 12- 50(Longer)

Motor

1.5HP

2HP

Speed

1500 R.P.M

1500 R.P.M

Machine Size(MM)

1650x700x1750

1750x700x1750

Back Beam Creel Ends

4-8

4-8

260 Ends (130 Ends Left and 130 Ends Right)

280 Ends (150 Ends Left and 150 Ends Right)

Normal Attachment

Inverter, Rubber Feeder, 260-300 Yarn Creel Position, 4-8 BeamPosition,Tool box,Auto
StopDevice, Automatic Oiling, Weight Block, Beam Holder.

Optional Attachment

Beam.Adiustable positive feeder for warp threads, Device for loose wefts effect on two edges.
